| Engine power | 231 kW @ 2100 rpm |
| Std. Bucket capacity | 1.8 m³ |
| Travel speed (High) | 5.5 km/h |
| Travel speed (Low) | 3.4 km/h |
| Maximum swing speed | 10 rpm |
| Arm breakout force | 196 kN |
| Bucket breakout force | 290 kN |
| Shipping length | 11267 mm |
| Shipping width | 3190 mm |
| Shipping height | 3800 mm |
| Track shoe width (std) | 600 mm |
| Boom | 6400 mm |
| Arm | 3200 mm |
| Digging reach | 11100 mm |
| Digging reach on ground | 10900 mm |
| Digging depth | 7340 mm |
| Vertical wall digging depth | 6460 mm |
| Cutting height | 10240 mm |
| Dumping height | 7160 mm |
| Minimum front swing radius | 4465 mm |
| Model | Cummins L9 |
| System maximum flow | 333 L/min |
| System pressure | 34.3 MPa |
| Operating weight | 39000 kg |
| Engine power | 214 kW @ 2100 rpm |
| Std. Bucket capacity | 2.0 m³ |
| Travel speed(High) | 5.5 km/h |
| Travel speed(Low) | 3.4 km/h |
| Maximum swing speed | 10 rpm |
| Arm breakout force | 227 kN |
| Bucket breakout force | 290 kN |
| Shipping length | 11450 mm |
| Shipping width | 3190 mm |
| Shipping height | 3800 mm |
| Track shoe width (std) | 600 mm |
| Boom | 6400 mm |
| Arm | 2900 mm |
| Digging reach | 10728 mm |
| Digging reach on ground | 10527 mm |
| Digging depth | 6890 mm |
| Vertical wall digging depth | 5085 mm |
| Cutting height | 9818 mm |
| Dumping height | 6655 mm |
| Model | Cummins L9PLUS |
| System maximum flow | 2×351 L/min |
| System pressure | 34.3 MPa |
