| Operating Weight | 49,500 kg |
| Stadard Bucket Capacity | 3.2 m³ |
| Swing Speed | 8.5 r/min |
| Arm Digging Force(ISO) | 268/287 kN |
| Shipping Width | 3,340 mm |
| Shoe Width | 600 mm |
| Max. Digging Reach on Ground | 10,388 mm |
| Max. Vertical Wall Digging Depth | 5,204 mm |
| Max. Dumping Height | 7,038 mm |
| Engine | Cummins QSM11 |
| Main Pumps Total Flow | 2×380 L/min |
| Rated Power | 280 kw@ 2,000 rpm |
| Travel Speed (Hight/Low) | 5.3/3.1 km/h |
| Bucket Digging Force(ISO) | 290/310 kN |
| Shipping Length | 11,515 mm |
| Shipping Height | 3,810 mm |
| Max. Digging Reach | 10,625 mm |
| Max. Digging Depth | 6,521 mm |
| Max. Cutting Height | 9,977 mm |
| Min. Front Swing Radius | 4,645 mm |
| Emission Regulation | Stage ⅢA/CN III |
| Relief Pressure, main | 34.3 MPa |
