Reliable
BX50 planetary transmission with high transmission efficiency is used.
LG A515 drive axle is adopted with rear axle swing design to provide strong bearing capacity and high reliability.
Standard 18 ply rating 23.5-25 tyres with superior wear resistance are adopted, which are more suitable to heavy load working conditions in mines.
Parker multiway valves, Permco working pumps and hydraulic components which are reliable and highly efficient are adopted.
Energy-efficient
Energy-efficient low RPM engine meeting China II emission standard requirements and highly-efficient large-capacity torque converter are perfectly combined to realize comprehensive energy conservation by 20%;
Comfortable
Three-level damping;
Cab space increased by 15%, indoor noise reduced to 80dB;
Mechanical suspended seat;
Curved glass with broad view.
Convenient
Engine hood and heat dissipation hood are designed with a large opening respectively to provide larger space for maintenance;
Oil filter, fuel filter and air filter are arranged at the same side to facilitate maintenance.
| Bucket capacity(m³) | 3 |
| Operating weight(kg) | 17450 |
| Rated load(kg) | 5000 |
| Rated power(kW) | 162 |
| Length×Width×Height(mm) | 8180x3024x3423 |
| Wheel base(mm) | 3200 |
| Max.dumping height(mm) | 3040 |
| Dumping distance(mm) | 1095 |
| Steering angel(°) | 35 |
| Engine Model | Weichai WD10G220E23 |
| Emission standard | China Phase II |
| Max.tractive force(kN) | 165 |
| Max.breakout force(kN) | 175 |
| Gears() | Forward 2 reverse 1 |
| Total time(s) | 10 |
| Fuel tank capacity(L) | 260 |
Strategic Positioning for Construction and Quarry Experts
Designed specifically for professional operators in construction, quarrying, and agricultural sectors, the SDLG L956F serves as a reliable heavy-duty loader developed by leading excavator manufacturers. Its 5-ton capacity targets engineers and procurement teams focusing on efficient bulk material handling. This chinese excavator model ensures productivity improvements in demanding environments, meeting operational requirements for earthmoving, feeding crushers, and transporting aggregates with precision and consistency.Advanced Engine and Structural Engineering Capabilities
The L956F wheel loader integrates a robust 162 kW Weichai WD10G220E23 engine delivering superior torque at low RPMs, optimizing fuel consumption during continuous cycles. Its 3.0 m3 reinforced bucket combines impact and abrasion resistance, supporting breakout forces exceeding 175 kN and tipping loads beyond 10,000 kg. The long-wheelbase frame enhances stability under load, while ground-level maintenance access reduces downtime. This loader’s technical package supports system integration within existing heavy equipment fleets and complies with China Phase II emission standards, aligning it with modern sustainability and operational efficiency benchmarks.Industrial Application and Operational Value Across Sectors
The SDLG L956F's functional versatility addresses multiple sectors ranging from large-scale construction sites to mining-adjacent operations and agricultural yards. It optimizes loading workflows by efficiently handling soil, gravel, coal, and aggregates while maintaining consistent cycle times. The machine’s durability and powerful mining excavator-class features enable smooth integration into port facilities and stockpile management systems, enhancing throughput and minimizing total ownership cost for enterprises requiring dependable, heavy-load handling solutions.
Structural and System Design Enhancements
The L956F’s modular design combines a reinforced frame, long-wheelbase architecture, and a robust central articulation joint, ensuring enhanced stability and durability. These features, characteristic of leading large excavator innovations, extend service life under sustained heavy loads. Additionally, the loader’s 3.0 m3 reinforced bucket integrates abrasion-resistant materials typical of top-tier excavator manufacturers, designed to withstand continuous impact and reduce maintenance frequency. The strategically planned ground-level filter grouping facilitates easier servicing, reducing operational interruptions in demanding site conditions.
Operational Performance and User-Centric Design
This wheel loader offers unmatched reliability and optimized fuel efficiency through its advanced 162 kW Weichai engine, a recognized powertrain among chinese excavator providers. Operator-centric enhancements include a vibration-damping seat, climate control, panoramic visibility, and rear camera integration to improve safety and comfort during long shifts. The L956F’s breakout force and stable frame design maximize load handling capabilities, increasing productivity while minimizing operator fatigue. These attributes collectively contribute to a strong return on investment for businesses seeking robust, performance-driven material handling equipment.
Construction Site Material Handling and Logistics
In construction environments where loading soil, gravel, and bulk materials is critical, the SDLG L956F operates as a key productivity enhancer. Site managers rely on its powerful big excavator classification to expedite loading cycles into dump trucks, ensuring minimal downtime. The loader’s traction force and breakout strength enable it to handle diverse terrain and materials efficiently, maintaining smooth workflow integration with conveyor and transport systems. Its adaptability makes it essential for maintaining scheduled project timelines and optimizing resource allocation within heavy machinery fleets.
Quarry and Mining-Adjacent Loading Operations
Within quarry and mining-adjacent contexts, the SDLG L956F supports high-frequency feeding of crushed aggregates and minerals to downstream crushers and stockpiles. Its structural design and robust drivetrain meet operational demands typical of mining excavator applications, enabling consistent cycle times and compliance with emission controls. Integration with site-wide material management systems equips operators to monitor performance metrics and schedule preventive maintenance, ensuring continuous productivity and reducing operational risk in challenging industrial environments.
At EROTZA, we specialize in designing and supplying safe, elegant and inclusive adult wellness products. Our mission is to promote comfort, body positivity and pleasure through innovation and discretion. We curate over 1,300 premium items from leading global brands, each crafted with body-safe materials and thoughtful engineering. Every product reflects our dedication to diversity and ethical manufacturing. We maintain strict quality control, eco-friendly packaging and discreet worldwide shipping. Our customer-care experts ensure personalized guidance and reliable after-sales service. At EROTZA, pleasure is about empowerment — helping people express themselves confidently, safely and freely.
1. What is the bucket capacity of the SDLG L956F Wheel Loader?
The standard bucket capacity is 3.0 m³, suitable for handling soil, gravel, sand, and rock in construction and mining operations.
2. What engine powers the L956F?
It uses a Weichai diesel engine rated at 162 kW, delivering strong torque and high reliability for continuous heavy-duty use.
3. Can it be used with different attachments?
Yes. The L956F supports multiple attachments such as forks, high-dump buckets and grapples, enhancing versatility for various industries.
4. What are the maintenance intervals?
Routine maintenance is recommended every 250 hours of operation, with major servicing at 2,000 hours to ensure optimal performance and longevity.
5. Is after-sales service available internationally?
Yes. SDLG’s authorized distributors and global parts centers provide service coverage across more than 100 countries.
