Application
Heavy duty vibratory rollers effect powerful centrifugal force and great static linear load,They are suitable for non-cohesive materials,such as sandy soil ,gravel,crushed stones,rock fillings and slightly cohesive soils,designed for large foundation constructions such as high-class highways ,mines,dams ,airports, harbors,railways and industrial areas etc.
Main Features
Technical parameters
|
Model |
|
GYS14 |
|
Operating mass |
kg |
14000 |
|
Statice linear load |
N/cm |
325 |
|
Vibration amplitude |
mm |
1.7/0.8 |
|
Centrifuel force |
Kn |
280/160 |
|
Vibration frequency |
Hz |
32 |
|
Travel apeed |
Km/h |
|
|
1st gear |
|
3.0 |
|
2nd gear |
|
5.5 |
|
3rd gear |
|
15 |
|
|
|
|
|
Ground clerance |
mm |
450 |
|
Electrial voltage |
V |
24 |
|
Tire size |
|
23.1-26 |
|
Grade ability |
% |
30 |
|
Turning radius |
mm |
7000 |
|
Overall dimension (LxWxH) |
mm |
5900x2250x3000 |
|
Vibration drum diameter |
mm |
1500 |
|
Drum width |
mm |
2100 |
|
Wheel base |
mm |
3010 |
|
Diesel egnine power |
Kw |
112/2200rpm |
|
Diesel egnine model |
|
CUMMINS 6BT5.9 |
|
Fuel tank capacity |
L |
300 |
|
Hydraulic tank capacity |
L |
250 |
